Features:
• Designed for transportation of luggage, bulky goods, plants, sport equipment, parcels etc.
• Body and roof constructed from 0.9mm corrosion resistant electro-galvanised sheet steel.
• Pad-lockable doors have heavy-duty robust hinges for longevity
• Pad-lockable spare wheel holder mounted on left mudguard
• Adjustable jockey wheel 6 inch
• Adjustable rigid support legs for uneven ground
• 7 x tie-down rings
• Sides are strengthened by formed hat-sections which prevents drumming and vibration.
• New aerodynamic round nose creating additional storage space.
• Including spare wheel 165x13 inch
• The trailer has a design registration No. F2004/0491, since 15 April 2004. Copyright also applies in respect of the trailer.
| Dimensions |
| A | Height (over all) | 1820 mm |
|---|
| B | Height (side) | 1350 mm |
|---|
| C | Length (body) | 2690 mm |
|---|
| D | Length (over all) | 3235 mm |
|---|
| E | Width (inside) | 1200 mm |
|---|
| F | Width (over all) | 1660 mm |
|---|
| G | Ground Clearance | 215 mm |
|---|
| Technical Info |
| Tare Mass | 340 kg |
| GVM | 750 kg |
| Pay Load | 410 kg |
| Brakes | No brakes |
| Axle Length | 1480 mm |
| Axle Capacity | 1250 kg |
| Leaf Springs | 8 blade |
| Wheels | 165 x 13 inch |
| Doors |
| Door (rear - height) | 1010 mm |
| Door (rear - width) | 845 mm |
| Door (side - height) | 1010 mm |
| Door (side - width) | 550 mm |
